Proper maintenance of the batteries in your motorhome prevents you from ending up without power during your holiday. Regular maintenance is essential. Measure the voltage of both batteries. Clean the battery terminals. Top up the leisure battery regularly. Check electrical connections for corrosion. These simple actions extend the service life of both the starter battery and the leisure battery. They take little time. They make the difference between carefree enjoyment and unexpected problems on the road. Discover how to keep your motorhome ready to go with practical steps.
A motorhome has two important types of battery. Each type has its own function. The starter battery delivers the peak current. This current is needed to start the engine. The leisure battery provides power for lighting, the fridge and other electrical appliances. Without proper maintenance, both batteries will let you down. This often happens at exactly the wrong moment.
Before you set off, it is sensible to carry out a thorough check. Read more about motorhome checks and maintenance to prepare your motorhome properly for your next trip.
Basic rules for both battery types
Starter battery or leisure battery, both types of battery require the same basic rules. These actions form the basis of good maintenance and help you to prevent problems.
- Clean the battery terminals regularly with a paper towel and check there is no corrosion, dirt or loose cables
- Measure the voltage monthly with a voltmeter (measuring device for electrical voltage) and recharge the battery if it drops below 12.6V
- Prevent deep discharge by never discharging deeper than recommended and always recharge fully after use
- Store batteries upright, frost-free and out of direct sunlight in a cool, dry place
Apply these rules consistently. This way you avoid sulphation. Sulphation is a common cause of capacity loss. Sulphation occurs when a battery is undercharged for a long period. Crystals then form on the lead plates. These crystals reduce performance and significantly shorten service life.
‘ Maintenance-free does not mean they don’t need any attention. ’
How do I test my motorhome’s starter battery?
The starter battery delivers the powerful surge of current. This surge is needed to start the engine. Modern starter batteries are often maintenance-free. Maintenance-free does not mean they don’t need any attention. These batteries also require regular checks.
Measure the voltage with a voltmeter (measuring device for electrical voltage). A healthy starter battery has a voltage between 12.6V and 12.8V. Measure this with the engine switched off. Is the voltage lower than 12.4V? Then recharge. Also check the wiring for loose wires, melting or discolouration. These are signs caused by overloading or poor connections.
To charge the starter battery, use a charger with a voltage of 13.8V to 15.0V. This can be via the alternator or a constant-voltage charger (charger with fixed voltage). Trickle charging is a good option for slow charging without haste. Set the charger to 13.2V to 13.8V with a current of no more than 1A (ampere, the unit of electric current). Fast charging goes up to 15.6V. Keep the battery temperature below 50°C.
Winter tips for the starter battery
For long-term storage, disconnect the starter battery. Store the battery in a warm place. Cold temperatures reduce performance. An insufficiently charged battery can freeze. Check the voltage every six months and recharge when needed. This prevents the battery from becoming damaged while the vehicle is not in use.
Maintaining and charging the motorhome leisure battery
The leisure battery supplies power to all the electrical facilities in your motorhome. This type of battery comes in several versions: lead-acid, AGM (Absorbent Glass Mat, maintenance-free battery with fibreglass mats), GEL (gel battery with gel-like electrolyte) and lithium. Each type requires its own approach.
Lead-acid and semi-traction batteries require a monthly check of the acid level. The plates should be ten millimetres below the water level. Top up with distilled water if necessary, never with battery acid. AGM, GEL and VRLA batteries (Valve Regulated Lead Acid batteries) are completely maintenance-free. Never open them and only clean them with a damp cloth. Do not use chemicals.
Lithium batteries, such as LiFePO4 (lithium iron phosphate, a widely used type of lithium battery), require even less maintenance. Wiping with a damp cloth is sufficient. Fully charge the battery before storage. Disconnect the battery from both the charger and the load. This prevents deep discharge.
Practical tips for leisure batteries
Connect the leisure battery to a trickle charger in winter (charger with a low constant current that keeps the battery topped up). This can be continuously in a shed or for two hours a day, depending on your set-up. Without an automatic switch, systems often draw power. Even when the motorhome is parked up. Recharge the battery. This prevents it from running flat. That way you avoid damage.
Measure the voltage regularly. A healthy leisure battery has a voltage of at least 12.6V. Does the voltage drop further? Then fully recharge to prevent sulphation. This applies to a 12V system. The capacity of the leisure battery is at least 20 per cent of the output of the inverter. This ensures optimum performance.
Solving motorhome battery problems on holiday
Good maintenance prevents many problems. Even so, faults sometimes occur on the road. Recognise the signs in time. Otherwise, a minor fault can soon grow into a major interruption to your trip.
Won’t the engine start? Is it turning over slowly? First check the voltage of the starter battery. Is it lower than 12V? Then the battery is too flat. Recharge it with an external charger. Alternatively, start the engine using jump leads connected to another motorhome or car. Also check the battery terminals for corrosion. Even a thin layer of green or white powder disrupts the contact.
Have the electrical facilities stopped working? The problem is probably with the leisure battery. Measure the voltage and check that all connections are firmly attached. Loose cables cause voltage drops. Devices then stop working. Also check whether the circuit breaker has tripped due to overloading.
Preventive action on the road
Take a voltmeter (measuring device for electrical voltage) with you and measure the voltage of both batteries every few days. That way, problems already show up. They have not actually occurred yet. Always take distilled water with you for lead-acid batteries. Also take a small brush to remove corrosion. A simple tool kit and a tube of contact spray make all the difference on the road.
‘ Good preparation prevents surprises during the first days of your trip. ’
Storage and preparation before departure
For long-term storage, fully charge both batteries. Disconnect them and store them in a warm, dry place. Use a trickle charger (charger with a low constant current that keeps the battery topped up) during extended periods of inactivity. This charger prevents sulphation. It supplies a small, constant current that keeps the battery topped up without overcharging it.
Carry out a visual check before departure. Check the battery terminals for corrosion. Test the voltage and recharge if necessary. Inspect all electrical connections. Check that they are firmly attached. Good preparation prevents surprises during the first days of your trip.
Do you go on longer trips? Do you often use many electrical appliances? Then consider upgrading to lithium batteries. Lithium offers better performance and a longer service life. It requires less maintenance than traditional lead-acid batteries. It is an investment that pays off in convenience and reliability.
Discover more about motorhome maintenance
Proper battery maintenance is just one part of a well-prepared motorhome trip. On the Traveller Tips website you can find much more information about technical checks, practical preparations and useful tips for on the road. Get your motorhome perfectly ready for every journey. That way you avoid surprises during your holiday.
Frequently asked questions
Always keep your leisure battery well charged and prevent deep discharge by switching off consumers when the voltage becomes too low. Before departure and on the road, check the battery voltage regularly with a voltmeter and recharge in good time via the alternator, solar panel or battery charger. Make sure the battery terminals and cabling are clean, corrosion-free and firmly attached to avoid voltage drops or faults. Consider a battery monitoring system or voltage guard that automatically disconnects consumers when the battery voltage is too low.
Before you set off on a long trip, check whether both the starter and leisure batteries are clean and whether the terminals are free from corrosion and firmly attached. Measure the battery voltage with a voltmeter and make sure it is around or above 12.6V; fully charge the battery or batteries if the voltage is lower. For lead-acid batteries, if applicable, check the fluid level and top up with distilled water if necessary. Finally, test whether all electrical systems (starting the engine, lighting, fridge, pumps) work properly on battery power.
Keep the battery terminals clean and dry, check regularly for corrosion and ensure all cable connections are firmly attached. Measure the voltage roughly once a month and recharge as soon as it drops below about 12.6V, so that deep discharge is avoided. Store the batteries upright, dry, frost-free and out of direct sunlight, especially during longer periods of non-use. If possible, disconnect the battery during storage and use a suitable trickle charger to keep it in good condition.
Ideally, fully charge your leisure battery using a good battery charger or charge controller, and avoid deep discharge by not allowing the voltage to drop below about 12.0–12.2V. Use energy-intensive appliances (such as a coffee maker or hairdryer) mainly while you are charging (driving or on hook-up), so the battery is less heavily loaded. Make sure your lighting and fridge are as efficient as possible (for example LED and an economical compressor fridge) so that you can reserve your battery capacity chiefly for comfort moments. Check the battery voltage regularly and recharge in good time so that you always have enough reserve for lighting, the water pump and other essential facilities.
Difficult starting, a weak or clicking starter motor and dimming lights are strong signs that the starter battery is causing problems. If the lights or appliances in the living area quickly become weaker, cut out, or the voltage regularly drops below about 12.6V, the leisure battery may be worn out. Visible corrosion, a swollen casing, hot or discoloured cables and having to recharge frequently also point to a battery that is due for replacement. Persistent voltage dips despite fully charging usually mean the battery has lost its capacity.
